Ranger RP-20FC Oil Filter Crusher with Stand - 10-Ton Capacity

The Ranger RP-20FC Oil Filter Crusher with Stand delivers 10 tons of air-operated crushing force to handle used oil filters and cans efficiently. It reduces filters to just 20%–25% of their original size while removing up to 95% of the residual oil for easy recovery. Featuring a built-in collection chamber, downspout, and rugged stand, this crusher ensures clean, compliant, and cost-effective oil waste management. Designed for automotive and light truck filters, it helps shops save on disposal costs and stay EPA-compliant. The heavy-duty stand supports up to 230 lbs of oil, allowing 5-, 16-, and 55-gallon tanks to fit easily below for efficient drainage and storage.

Specifications:

• 10-ton air-operated oil filter and can crusher

• Reduces filters to 20%–25% of their original size

• Removes up to 95% of residual oil

• Crushes cans in only 20 seconds

• Complies with EPA environmental standards

• No-mess design minimizes spill hazards

• Single-control valve operation

• Exclusive X-shape bevel ensures perfect filter alignment

• Welded steel plate construction for durability

• 12.5" diameter cylinder provides up to 20,000 lbs. pressure

• Transparent safety door automatically stops operation when opened

• Includes pressure regulator and air moisture separator

• 100% air-operated for minimal maintenance

• Stand supports over 230 lbs. of oil

• Accommodates 5-, 16-, and 55-gallon oil storage tanks

• Easy setup and space-efficient design for professional shops

• Overall Height: 29.5" (749 mm)

• Overall Width: 17" (432 mm)

• Overall Depth: 17" (432 mm)

• Chamber Opening Height: 10.25" (260.35 mm)

• Chamber Opening Width: 8" (203 mm)

• Chamber Opening Depth: 11" (279 mm)

• Average Cycle Time: 15 – 20 sec

• Air Input: 125 – 175 psi

• Unit Weight: 326 lbs. (148 kg)

• Shipping Dimensions: 43" x 22" x 22" (1,092 mm x 558 mm x 558 mm)

A $395 surcharge from the freight carrier will be applied if no forklift or loading dock is available at the delivery location.
